ReaLite®– Ultra-Lightweight Ceramic Proppant – a patented product

Features:

  • US and Internationally patented product

  • Rainbow's most cost-effective proppant

  • Ultra-lightweight, with an apparent specific gravity of 2.40 g/cc and a bulk density of 1.30 g/cc

  • Provides 50 percent higher strength, improved conductivity, more thermal stability, and better placement than premium resin-coated sand

  • Excellent for slick water fracturing applications and horizontal completions

  • Low viscosity fracturing fluid and slow pumping rates can be used to reduce wear and cost on fluid carrying and pumping equipment

  • Minimum premature settling to achieve more efficient proppant placement

  • Available in two standard sizes: 30/50 and 40/70


Detailed data sheet

Download here

PropLight® – Lightweight Ceramic Proppant

Features:

  • High performance

  • Provides one of the highest fracturing conductivities available for applications in wells with moderate depths

  • Lightweight, with an apparent specific gravity of 2.80 g/cc and a bulk density of 1.50 g/cc, which is similar to those of frac sands

  • Exceptional chemical resistance and thermal stability

  • Low viscosity fracturing fluid and slow pumping rates can be used to reduce wear and cost on fluid-carrying and pumping equipment

  • Low viscosity fracturing fluid and slow pumping rates can be used to reduce wear and cost on fluid carrying and pumping equipment

  • Minimum premature settling to achieve more efficient proppant placement

  • Available in three standard sizes: 20/40, 30/50, and 40/70


Detailed data sheet

Download here

PropMaster® - Intermediate-Strength Proppant

Features:

  • Cost competitive

  • Superior conductivity and permeability in moderate- to high-stress environments, as determined by independent lab testing

  • Designed for high performance under closure stresses of up to 14,000 psi

  • Increased and field-proven crush resistance and thermal stability under high closure pressure

  • Solid and reliable performance in intermediate depth oil and gas wells with low to moderate permeability

  • Exceptional roundness and sphericity to minimize the friction and wearing on fluid carrying and pumping equipment

  • Available in four standard sizes: 16/30, 20/40, 30/50, and 40/70


Detailed data sheet

Download here

PropRaider® - High-Strength Sintered Bauxite Proppant

Features:

  • Rainbow's highest strength proppant

  • Maximum conductivity, highest crush resistance, and excellent thermal stability

  • Generally used in the deepest oil and gas wells, where other proppants are not applicable

  • Field-proven performance

  • Exceptional roundness and sphericity to minimize friction and wearing on fluid carrying and pumping equipment

  • Available in three standard sizes: 16/30, 20/40, and 30/50


Detailed data sheet

Download here
